MEETING SMART BOARD SKYWORTH


OLED INTERACTIVE gamme Infinity en partenariat avec SKYWORTH

Des écrans  65″(165cm) , le 84″(213cm) ,  mais aussi disponible jusqu’à 110″ (280cm) sur demande. Toutes les dalles sont disponible en version tactile multipoint UHD, des produits de très haute qualité proposés aux écoles, pressmédia, entreprises ainsi qu’à la commission européenne.

1.System

◆ Based on Android 5.1.1 system

◆ 4 core high performance processor 1.2GHz master frequency

◆ 2G DDRIII main memory

◆ Built-in 16G flash memory, supports external TF Card

◆ wifi module,supports 802.11 b/g/n ,2.4G+5.8G two modes

◆ 100M network interface

◆ 4K UKD resolution

◆ I/O interface: 6x USB /1xVGA/1x RJ45/1x Audio/1xHDMI/1xTouch OUT



It’s a « efficient, convenient and low-cost » conference system.

1) LGD 4K resolution, 3840*2160,IPS screen; touch frame support front access; writing by Pen, Finger and other.

2) U- Share supports 8 device access, while supports 4 different mobile devices share to the smart board at the same time.

3) Support up to10 points touch, writing, touch accuracy less than 2mm, 3 kinds of gestures eraser mode.

2.Specification for 86 inch ask for more

Item Parameter
Name Smart Board
Model SKY86SXE0H
Panel Screen 86 inch
Back Light LED
Resolution 3840×2160
Display size(mm) 1896mm(W) *1067mm (H)
Response Time 6.5ms
Brightness 350cd/m²
Contrast 1200:1
View Angle 178°
Color 16.7M
Ratio 16:9
Build-in

ANDROID

System

CPU 4-core processor 1.2GHz frequency
Memory 2G
Built-in flash memory 16G
Operating System Android 5.1.1
Speaker 15W×2



Storage TF card,U disk
Signal

Ports

Network Port RJ45,wifi,
USB Port 6 ay(5 way USB2.0,1 way USB3.0)
HDMI IN 1 way
VGA IN 1 way
Earphone port 1 way
Working Environment Temperature 0℃~50℃
Humidity 10%~90%
Storage Environment Temperature -20℃~60℃
Humidity 5%~90%
Input voltage AC220V
Demand current





≤1.5A

3A

0.5A

Accessories User Manual、Pen*2,U-Share*1,Power cable*1,
Product Size 2042*1221*110 mm
Package Size 2245*1350*315 mm
Net Weight 95Kg
Gross Weight 115Kg
